Welcome to Spotcom

Discover the World of Reliable Industrial Wireless

Elpro 415 long rane telemetry industral wireless
AES256 Encryption - ProMesh - 170-458MHz - Licence/Licence Free

Here's Technician John - Working with the 415U-2 Condor

Some of Our Customers...... Thank you!

Products

Telemetry Antenna

Spotcom's association with Elpro Technologies (now part of the Aquamonix) goes back a long way- allowing us to really get to know their products. They are designed and built to exacting standards, to give first class performance even in the most demanding circumstances. When others fail, the Elpros step up to the mark- that is exactly what is needed if the application demands reliability. Hence, over the years, they have become the radio of choice for many Utilities, where their performance and reliability track record has been firmly established.



We are able to supply radios on a uniquely wide range of frequencies, ranging from  5 GHz, down to the newly available "60 MHz" or Band 1 VHF. This lower frequency has very interesting propagation characteristics, and has been proven to provide stable connectivity where the more  conventional UHF frequencies simply cannot.



Antennae play a key part in the radio system, as do the feeder cables and lightning protection. Therefore, we are equally careful with our selection of ancillary items, and recommend the best for the application in hand.

Introducing: Condor Series


The 415U-2 introduces ELPRO's newest combined I/O and modem platform that sets the stage for future product developments. This unique capability allows customers to inexpensively gather I/O data from remote locations without the need of a full RTU/PLC. When a remote site does have an RTU, the customer can use a 415U-E Ethernet radio and implement in the same network as the 415U-2 I/O radios to accomplish a seamless solution for connectivity of devices.

Spotcom is proud to announce the release of Elpro's CONDOR SERIES line of high speed licensed and license-free radio telemetry products.
Features

415U-2-C

Data Sheet

  • Exceeding 140 kbps data throughput (25 kHz channel and compression)

  • Secure data protection with WPA and AES256 encryption

  • Full Ethernet protocol over the air provides a standards-based flexibility to support future and legacy devices • ProMesh automatic path selection and network formation

  • Internal Web dashboard for immediate view of local I/O

  • Supports multiple data rates simultaneously for high performance over short and long communication links

  • Frequency agility roaming provides reliability and flexibility within the network architecture

  • Over-the-air context-based data compression and forward error correction provides maximum reliability and transmission efficiency

  • Redundancy modes for base, repeater, and remote

  • Wireless point-to-point or multipoint I/O and gateway functionality

  • Modbus TCP and RTU I/O gateway

  • DNP3 I/O gateway, including internal status registers

  • Standard Ethernet bridge default to allow modem function for external Ethernet host devices (full L2/L3 network support)

  • 340–480 MHz frequency range in just 2 models

  • 10 mW to 10 W RF power configurable, license or license-free

  • Software configurable wireless channel bandwidth supporting 6.25, 12.5, 25.0 kHz

  • Integrated digital, pulse, and analog I/O

  • Gather-scatter/block mapping and integrity checking transmissions for efficient event triggered peer-to-peer I/O

  • Over-the-air network diagnostics and configuration

  • Expandable I/O for local alarms and inputs/outputs

415U-E-C

Data Sheet

industrial radio industrial wireless radio telemetry industrial radio telemetry radio modem industrial radio modem wireless Ethernet serial modem wireless modem industrial radio communications radio telemetry uk radio modem long range scada radio modem plc radio modem rs232 rs485 radio site surveys electrical services industrial radio industrial wireless radio telemetry industrial radio telemetry radio modem industrial radio modem wireless Ethernet serial modem wireless modem industrial radio communications radio telemetry uk radio modem long range scada radio modem plc radio modem rs232 rs485 radio site surveys electrical services industrial radio industrial wireless radio telemetry industrial radio telemetry radio modem industrial radio modem wireless Ethernet serial modem wireless modem industrial radio communications radio telemetry uk radio modem long range scada radio modem plc radio modem rs232 rs485 radio site surveys electrical services

Support and Services.

We offer the re-assurance of "no-fuss" support if it is needed, and we provide on-site services.



Site Surveys asses and test the viability of links, and result in our recommendation for the required equiment for the project, followed by a quote for the required items.



Commissioning Assistance is available- popular with those inexperienced with radio, this often includes the programming of the radios along with training, as required.



Troubleshooting- available should things not be as expected!

60 MHz Radio Survey

Surveying underway. The convetional 458 MHz radios showed no signs of life on this badly occluded link, as predicted by our "desktop" survey. The 60 MHz radios however, had no problem establishing solid communications.

Questions?

Feel free to contact us!   Sales@SpotcomLtd.co.uk
